WL28
WL28(A01-01) Tubing traction drive hydraulic Diagram
- 101000015513Not stockedscrew joint×3
- 201000022386Not stockedcheese head screw×2
- cheese head screw - 1000085464×2
- 401000412454Not stockedHose×1
- 501000442619Not stockedscrew joint×1
- O-RING - 1000249612×1
- EV18LOMDA3C - 1000298483×1
- cheese head screw - 1000085460×2
- 901000015430Not stockedu-washer×2
- 1001000015405Not stockedhexagon nut×2
- 1101000436911Not stockedHose×1
- cheese head screw M6x60-8.8 A2C - 1000085461×2
- 1301000436973Not stockedclamp×1
- 1401000424157Not stockedHose×1
- 1501000436860Not stockedhose fitting×1
- 1601000424161Not stockedHose×1
- 1701000436843Not stockedhose fitting×1
- 1801000434248Not stockedHose×1
- 1901000434247Not stockedHose×1
- 2001000434246Not stockedHose×1
- EW22LOMD - 1000020261×2
- BLOCK-CLAMPING - 1000222578×1
- GE22LM33X2EDOMD - 1000417356×1
- GZ18LA3C - 1000018398×1
- NON RETURN VALVE RHD 18-L 2,0bar - 1000178597×1
- ET18LOMDA3C - 1000085077×1
- GE18LM22X1,5EDOMDA3C - 1000085104×1
- GE18LM27X2ORA3C - 1000260785×1
- EW28LOMDA3C - 1000085091×1
- GE22LM27X2ORA3CX - 1000183818×1
- 3101000422042Not stockedpipe line×1
- 3201000028698Not stockedscrew joint×1
- O-RING - 1000249612×1
- 3401000022386Not stockedcheese head screw×4
- 3501000030951Not stockedspring washer×4
