WL28

WL28(A01-01) mounting Diagram

Exploded parts diagram of the mounting of a Wacker Neuson WL28(A01-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 501000274540Price
    U-WASHER - 1000274540×12
  • 601000295130Price
    guide bushing - 1000295130×4
  • 701000274535Price
    hex screw - 1000274535×8
  • 801000274071Price
    Hexagon nut M20-10 ISO 4032-Geomet 321 - 1000274071×8
