WL28

WL28(A01-01) fastenframe Diagram

Exploded parts diagram of the fastenframe of a Wacker Neuson WL28(A01-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 101000449009Not stocked
    fastening frame×1
  • 111000459409Not stocked
    frame×1
  • 201000193759Price
    cable strap - 1000193759×4
  • 301000356352Price
    Rivet - 1000356352×4
  • 401000282739Price
    sockets - 1000282739×1
  • 501000282738Price
    sockets - 1000282738×3
  • 601000013022Not stocked
    hexagon nut×2
  • 701000015343Not stocked
    hex screw×2
  • 801000047828Not stocked
    hex screw×2
  • 901000013027Not stocked
    washer×6
