EW65
EW65 AIR-CONDITIONING PLANT (OPTION) Diagram
- 11000461232Not stockedair condition system×1
- 21000015437Not stockedlock washer×6
- 31000019450Not stockedcheese head screw×6
- 41000013027Not stockedwasher×6
- 51000313213Not stockedround nozzle×1
- HOSE CLAMP - 1000083246×2
- air suction hose - 1000287563×1
- 81000313229Not stockednozzle×4
- 91000323174Not stockedscrew×8
- Sensor - 1000344369×1
- plate - 1000329991×1
- hex screw - 1000273341×2
- shim - 1000304107×2
- 141000316099Not stockednut×2
- plate - 1000329005×1
- 161000314104Not stockedheater filter×1
- 171000323773Not stockedheater filter×1
- screw M6x12 ISO7380-2 - 1000165459×3
- 191000347788Not stockedfixing plate×1
- 201000347841Not stockedfixing plate×1
- rubber-spacer - 1000347842×4
- 221000347730Not stockedadjust motor×1
- 231000347883Not stockedair cleaner×1
- 241000347884Not stockedblower×1
- 251000337372Not stockedsensor×1
- 261000347886Not stockedmodul×1
- 271000347888Not stockedevaporator×1
- 281000347889Not stockedheater register×1
- 291000347911Not stockedexpansion valve×1
- 301000347912Not stockedsensor×1
- 311000347917Not stockedwater valve×1
- hose - 1000347920×1
- hose - 1000347931×1
- 341000347932Not stockedair dryer×1
- 351000347933Not stockedpressure sensor×1
- 361000347934Not stockedsensor×1
- internal temperature sensor - 1000374981×1
- O-RING - 1000333126×1
- O-RING - 1000333125×1
