EW65
EW65 CYLINDER HEAD, VALVE COVER option Diagram
- 11000433730Not stockedcylinder head×1
- lock plug - 1000205727×5
- lock plug - 1000199587×3
- stud bolt - 1000244770×2
- 51000433784Not stockedvalve seat×4
- 61000433992Not stockedexhaust valve×4
- 71000433991Not stockedintake valve×4
- 81000433782Not stockedvalve seat×4
- Plug - 1000199593×2
- VALVE SHAFT SEAL - 1000199797×8
- spring - 1000433783×8
- Spring seat - 1000199688×8
- valve wedge - 1000199656×12
- Plug - 1000199590×7
- Shaft 1000199438×1
- Shaft - 1000205762×1
- o-ring - 1000224976×1
- ROCKER ARM - 1000199762×4
- HEXAGON NUT - 1000245343×8
- SET SCREW - 1000199919×8
- U-WASHER - 1000202539×6
- Spring - 1000199652×3
- ROCKER ARM - 1000199761×4
- 241000347062Not stockedhex screw×1
- stud bolt - 1000199471×4
- valve cap - 1000244937×8
- Gasket - 1000314662×1
- Bolt - 1000281999×1
- Nut - 1000199527×4
- 301000433872Not stockedsuction manifold×1
- 311000314626Not stockedseal suction manifold×1
- 321000320960Not stockeddistance piece×1
- 331000314627Not stockedseal suction manifold×1
- screw - 1000389198×8
- O-ring - 1000256801×1
- sensor - 1000433882×1
- O-ring - 1000433850×1
- sensor - 1000433883×1
- Screw - 1000257254×1
- throttle - 1000433956×1
- 411000433945Not stockedreduction nipple×1
- Screw - 1000130911×4
- 431000314618Not stockedseal×1
- plate - 1000433877×1
- SCREW - 1000205914×6
- seal - 1000316579×4
- nut - 1000433827×4
- 481000389212Not stockedcylinderhead cover×1
- o-ring - 1000224975×1
- Cover - 1000205611×1
- 511000307090Not stockedscrew joint×1
- 521000389155Not stockedhose clamp×2
- hose - 1000433847×1
- Breather - 1000308228×1
- SCREW - 1000130616×3
- hose - 1000389207×1
- O-ring - 1000328479×1
- Breather - 1000328478×1
- 1000403827 - 1000433942×4
- CONNECTION - 1000396015×1
- lodging nut - 1000245009×4
