DV90
DV90 AIR-CONDITIONING PLANT INST. (OPTION) Diagram
- 11000404470Not stockedhose aircondition system×1
- 21000388671Not stockedhose×1
- 31000388672Not stockedhose×1
- 41000404471Not stockedhose aircondition system×1
- heater hose ID15x3,5 - 1000261871×1.6
- heater hose ID15x3,5 - 1000261871×1.25
- heater hose ID15x3,5 - 1000261871×0.6
- 81000147152Not stockedwater valve×1
- hex screw - 1000158721×2
- hose sleeve - 1000267953×1
- 111000352605Not stockedhose sleeve×1
- 121000000558Not stockedscrew joint×2
- hose clamp - 1000267810×6
- 6-Point screw M8x80-8.8 A2C - 1000085319×2
- 151000015629Not stockedcover plate×2
- 161000015630Not stockedclamp body×2
- allen screw M6x25-8.8 A2C DIN912 - 1000085457×3
- Screw M6x40-8.8 A2C DIN912 - 1000085458×3
- 191000015430Not stockedu-washer×10
- sockets - 1000291567×5
- 211000357533Not stockedhexagon nut×4
- allen screw M6x16-8.8 A2C - 1000085455×1
- BRACKET - 1000338212×1
- plate - 1000401668×1
- 251000019593Not stockedcheese head screw×2
- 261000015431Not stockedwasher×2
- 271000015369Not stockedcheese head screw×1
- hose clamp RSGU 1 23/20 - 1000083248×1
- washer A 6,4 St A2C DIN9021 - 1000095343×2
- hose clamp - 1000083250×1
