TH412
TH412(T01-01) Engine tub Diagram
- 101000442533Not stockedengine sump×1
- 201000066219Not stockedplug×4
- 301000018400Not stockedhex screw×11
- 401000015430Not stockedu-washer×11
- HEX SCREW - 1000085382×10
- U-WASHER - 1000223000×6
- 701000049219Not stockedwasher×6
- 801000049000Not stockedhexagon nut×6
- hex screw - 1000085419×5
- Washer - 1000222875×10
- 1201000047392Not stockedhex screw×1
- self-locking nuts M6-8 A2C-DIN985 - 1000085588×2
- Washer M 6x20x1,25 - 1000222604×2
- COUNTERSUNK SCREW - 1000085528×2
- ovalhead screw - 1000085550×3
- 1901000539316Not stockedtop cover×1
- Sheet - 1000418150×1
- 2101000418375Not stockedfloor plate×1
- 2201000539305Not stockedtop cover×1
- 2301000410339Not stockedfloor plate×1
- 2401000450189Not stockedcover plate×1
- Foam - 1000432232×2
- Foam - 1000381602×1
- FOAM STRAP - 1000232095×0.15
- 2901000432706Not stockedfoam strap×2
- 3001000432704Not stockedfoam strap×1
- FOAM STRAP - 1000232095×0.04
