Excavator EZ38

EZ38 BUCKET OPERATION (OPTION) Diagram

Exploded parts diagram of the BUCKET OPERATION (OPTION) of a Wacker Neuson EZ38, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000076325Not stocked
    Hose×1
  • 21000076293Not stocked
    Hose×1
  • 31000022534Not stocked
    Hose×2
  • 41000146540Price
    SLHYDR 2SC 13 PN15 90 PD15 0 L2000 S0 - 1000146540×2
  • 51000146491Price
    SLHYDR 2SC 10 PN12 0 PD15 0 L1350 0 - 1000146491×2
  • 61000146887Price
    Hydraulicpipe 1000146887×2
  • 71000097905Price
    protecting hose - 1000097905×0.9
