Excavator EZ38

EZ38 LIFTING BOOM OPERATION Diagram

Exploded parts diagram of the LIFTING BOOM OPERATION of a Wacker Neuson EZ38, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000076293Not stocked
    Hose×1
  • 21000076325Not stocked
    Hose×1
  • 31000146539Price
    SLHYDR 2SC 13 PN15 90 PN15 0 L1700 S0 - 1000146539×1
  • 41000146543Price
    SLHYDR 2SC 10 PN12 90 PN12 0 L2000 S0 - 1000146543×1
  • 51000000542Price
    EW08LOMD - 1000000542×1
  • 61000015515Not stocked
    screw joint×2
  • 71000076331Price
    SLHYDR 1SCP6,0PN8 0 PN8 90 L1050 0 - 1000076331×1
  • 81000076405Not stocked
    Hose×1
  • 91000097905Price
    protecting hose - 1000097905×0.9
