DV90-2
DV90-2 skip Monitoring device Diagram
- switch - 1000400276×1
- 21000564118Not stockedshift plate×1
- cable - 1000254757×1
- 41000322839Not stockedfixing bracket×1
- screw - 1000223120×2
- BOLT M4x30 8.8 A2C-DIN912 - 1000082307×2
- 71000015431Not stockedwasher×3
- nut M4-8 A2C-DIN985 - 1000082547×2
- 91000019593Not stockedcheese head screw×3
