ET145
ET145 air cleaner Diagram
- Aircleaner 1000078928×1
- bracket airfilter - 1000078929×1
- 31000015343Not stockedhex screw×2
- 41000015437Not stockedlock washer×2
- 51000013027Not stockedwasher×2
- 61000032150Not stockedclamp×1
- air suction hose - 1000176904×1
- air suction hose - 1000180367×1
- 91000353075Not stockedhose×1
- dirt indicator - 1000150373×1
- airfilter insert - 1000113384×1
- airfilter element - 1000113383×1
- airfilter cover - 1000113385×1
- dustexhaust valve - 1000113387×1
- INTERMEDIATE PIECE - 1000188276×1
- 161000015348Not stockedhex screw×1
- 171000015438Not stockedlock washer×5
- Washer 10,5 St A2C - 1000092303×5
- 6-Point screw M10x40-8.8 A2C-DIN933 - 1000085412×2
- nut M10-8 A2C-DIN985 - 1000015408×2
- hose clamp 50-70mm - 1000083310×1
- hose clamp - 1000287571×2
- 231000015430Not stockedu-washer×2
- cheese head screw M10x25-8.8 A2C-DIN912 - 1000085468×2
- 251000015438Not stockedlock washer×2
- washer 10,5 A2C DIN125 - 1000015432×2
- allen screw M6x16-8.8 A2C - 1000085455×2
- 281000327374Not stockedhose×1
- 291000348322Not stockedlift eye×1
- 301000062662Not stockedpipe clamp×2
- 311000015436Not stockedlock washer×2
- 321000345997Not stockedpipe clamp×1
- socket head screw M8x12-8.8 A2C DIN912 - 1000085493×1
- 341000015431Not stockedwasher×1
- 351000015437Not stockedlock washer×1
- HOSE CLAMP 26-38mm - 1000083306×1
