ET145
ET145 Reversing Camera Diagram
- cable - 1000257303×1
- Camera - 1000468676×1
- cheese head screw M8x30-10.9 DACRO500-5 - 1000085497×2
- QUAD RING - 1000094570×2
- 51000015437Not stockedlock washer×2
- shim - 1000304107×2
- 71000013027Not stockedwasher×2
- screw M6x12 ISO7380-2 - 1000165459×2
- 91000344409Not stockedtension regulator×1
- Bracket - 1000344718×1
- 111000482508Not stockedbracket×1
- 121000434267Not stockedreversing warning×1
- 131000484918Not stockedwiring harness×1
- 141000362407Not stockedpin contact×2
- 151000027445Not stockedpin housing×1
- 161000027449Not stockedhousing×1
- 171000359612Not stockedplug connection×2
- 181000027438Not stockedbushing housing×1
- 191000027442Not stockedwedge×1
- protecting cap - 1000285334×1
