CRT60-74L
CRT60-74L Electrical cpl. Diagram
- ALTERNATOR-80A, LETRIKA - 5200016516×1
- SCREW-FLANGED, M8X70 - 5200016522×1
- SCREW-FLANGED, M8X80 - 5200016518×1
- SCREW M8 X 22 - 5000110757×1
- 55200016523Not stockedStarter motor×1
- BRACKET-ALTERNATOR - 5200016519×1
- SPACER-ALTERNATOR MOUNT - 5200016520×1
- SCREW M10 X 30 - 5000084164×2
- SPACER-ALTERNATOR MOUNT - 5200016521×1
- 175100016106Not stockedEngine wiring harness×1
- CABLE-ALTERNATOR - 5100016105×1
- 195100016107Not stockedEngine control module×1
- 205200016456Not stockedOil pressure switch×1
- 215200016457Not stockedTemperature sensor×1
- 225200016549Not stockedCam sensor×1
- 235200016550Not stockedGasket×1
- 245200016552Not stockedCrank sensor×1
- 255200016553Not stockedBracket×1
- 265200016554Not stockedSpacer×1
- 275200016555Not stockedSensor×1
