CRT60-74L
CRT60-74L Belt cpl. Diagram
- WHEEL- SPEED SENSOR - 5200016277×1
- Deadening disc - 5200016278×1
- SCREW M6 X 14 - 5000082357×4
- PULLEY - 5200016279×1
- 55200016280Not stockedBelt×1
- BOLT M16 X 1.5 - 5000126935×1
- 75200016331Not stockedCover×1
- SCREW M8 X 45 - 5000203346×15
- 95200016332Not stockedSeal-oil×1
- SLEEVE - 5200016333×1
- SPRING - 5200016334×1
- WASHER-COPPER - 5000159299×1
- PLUG - 5200016336×1
- O-ring - 5000159231×1
- PIN-DOWEL - 5000161080×2
