CRT60-74L

CRT60-74L Hydraulic Piping-Lower Cooler Diagram

Exploded parts diagram of the Hydraulic Piping-Lower Cooler of a Wacker Neuson CRT60-74L, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 765200015390Price
    Switch-Temperature 120f, NO - 5200015390×1
  • 875200025609Price
    OIL COOLER C20 - 5200025609×2
  • 885200025589Price
    OIL COOLER FAN C20 - 5200025589×1
  • 945200022925Price
    Tank-Breather,CRT60 4 Qt. - 5200022925×1
  • 945100028084Price
    CAP-CRT60 HYD TANK TOP VENTED - 5100028084×1
  • 1605000028707Price
    CLAMP-THREADED,.21-.63 - 5000028707×2
  • 1885200025586Price
    DUCT-OIL COOLER C20 - 5200025586×1
  • 3605000192759Price
    Fitting-Straight #10 ORF-#10 ORB - 5000192759×1
  • 3625000192761Price
    Fitting-45 degree #12 ORB - #12 ORFS - 5000192761×2
  • 3635200002093Not stocked
    Barbed fitting×1
  • 3695000081583Price
    FITTING #8 - 5000081583×3
  • 3705000119813Price
    FITTING-90 DEG-#10 ORBX10 ORFS - 5000119813×3
  • 3725000116177Price
    FITTING-ADAPTER,TEE - 5000116177×2
  • 3945000119955Price
    FITTING-STRAIGHT,#12 - 5000119955×1
  • 4115100029012Price
    Oil-Blue Hydraulic,Syn ISO68,5 Gal - 5100029012Unknown×1
  • 4115100029013Not stocked
    Hydraulic oil, Blue×1
  • 4405100016123Price
    Fitting,Straight MaleXORB Female ORB - 5100016123×1
  • 4415100016122Price
    Fitting-Straight Bleed #12 ORFS #4 SAE - 5100016122×1
  • 4435100016124Price
    Fitting-Tee Male,Female ORB - 5100016124×1
  • 4445100016125Price
    Fitting-Straight Orifice - 5100016125×1
  • 5005200021478Price
    Hose, CRT60 overflow bottle - 5200021478×1
  • 6125000193990Price
    HOSE - RH MOTOR CASE DRAIN - 5000193990×1
  • 6135000193991Price
    HOSE - LH MOTOR CASE DRAIN - 5000193991×1
  • 6185000193997Price
    HOSE - HYDRO TO RH MOTOR - 5000193997×1
  • 6195000193998Price
    HOSE - HYDRO TO LH MOTOR - 5000193998×1
  • 6205000193999Price
    HOSE - RH MOTOR TO COOLER - 5000193999×1
  • 6215000194000Price
    HOSE - LH MOTOR TO COOLER - 5000194000×1
  • 6225000194001Price
    HOSE - COOLER TO RH HYDRO - 5000194001×1
  • 6235000194002Price
    HOSE - COOLER TO LH HYDRO - 5000194002×1
  • 6245000194003Price
    HOSE - BREATHER TANK - 5000194003×1
  • 6335000080732Price
    O-RING .644 X.087 DURO90 3-908 - 5000080732×4
  • 6345000080734Price
    O-RING .924 X.116 DURO90 3-912 - 5000080734×2
  • 6355000080737Price
    O-RING .49 X .07 #8 ORFS 2-014 - 5000080737×1
  • 7015100016203Price
    Hose-CRT60 Bleed circuit - 5100016203×1
