RD880V-ROLLER, DOUBLE DRUM
RD880V Engine Compartment Diagram
- NUT-LOCK M6 HEX. - 5000010368×4
- WASHER-FLAT,M8,ZINC - 5000010622×2
- SCREW M6 X 20 HX.HD. - 5000011470×2
- 45000079576Not stockedShrink tube×2
- SCREW M5 X 16 HX.HD. - 5000011476×8
- LATCH-FLEXIBLE DRAW - 5000079309×2
- 75000079313Not stockedCover×1
- 85000079307Not stockedStrap×1
- SCREW M8 X 30 10.9,FLT - 5000034837×4
- WASHER B10.5 FLAT - 5000010621×8
- 115000079569Not stockedChain×2
- 125000079310Not stockedBumper spacer×2
- MOUNT-SCRAPER CENTER - 5000079203×1
- NUT-LOCK M8 HEX - 5000010367×4
- 155000080767Not stockedScraper×2
- NUT-LOCK M10 HEX. - 5000010365×4
- SCREW M8 X 18 HX.HD. - 5000013551×4
- SCREW M8 X 30 HX.HD. - 5000011456×12
- PLATE-STRIP - 5000079207×2
- SHOCKMOUNT 54 X 33-70SH,FRM A - 5000073131×4
- MOUNT-SCRAPER END - 5000079204×1
- SCREW M8 X 20,HX.HD,SER.FLG - 5000028404×7
- 235000079319Not stockedFront cover×1
- 245000085693Not stockedFront frame×1
- 255000110256Not stockedHinge×1
- NUT-LOCK M5 HEX. - 5000010369×8
