ET18-2
ET18-2 bucket cylinder Diagram
- 11000522876Not stockedbucket cylinder×1
- 21000566760Not stockedguide rail×1
- countersunk screw - 1000085531×2
- 41000553221Not stockedprotecting rail×1
- hex screw M10x20-8.8 A2C DIN933 - 1000085411×1
- 61000368878Not stockedlock washer×1
- plug M8 - 1000288011×2
- 81000068993Not stockedplug×1
- 91000564524Not stockedpiston rod×1
- 101000503044Not stockedguide bushing×1
- piston - 1000503047×1
- nut - 1000503077×1
- 131000015476Not stockedgrease nipple×2
- Bushing - 1000176338×1
- Bushing - 1000503075×1
- 161000015491Not stockedscrew joint×1
- 171000503025Not stockedseal kit×1
