Excavator 28Z3

28Z3 oil sump Diagram

Exploded parts diagram of the oil sump of a Wacker Neuson 28Z3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000148786Price
    Oilsump 1000148786×1
  • 21000071058Not stocked
    seal ring×1
  • 31000134824Price
    LOCK SCREW - 1000134824×1
  • 41000085197Price
    SCREW - 1000085197×3
  • 51000107492Price
    SCREW - 1000107492×11
  • 61000085173Price
    hex screw - 1000085173×1
  • 71000126868Price
    SCREW - 1000126868×1
  • 81000035794Not stocked
    sealing compound×1
  • 91000019590Not stocked
    hose clamp×1
  • 101000022322Not stocked
    drain coupling×1
  • 111000116059Price
    synthetic hose - 1000116059×0.5
  • 121000034616Not stocked
    drain coupling×1
  • 131000247615Price
    drain coupling - 1000247615×1
  • 141000234769Price
    drain coupling - 1000234769×1
  • 151000128333Price
    service valve motor oil - 1000128333×1
  • 161000307442Not stocked
    pipe seal×1
