Excavator 1404
1404 AUXILIARY HYDRAULICS OPERATION Diagram
- SLHYDR 1SC 13 PN15 45 PN15 0 L2300 S0 - 1000157841×1
- SLHYDR 2SC 10 PN12 45 PN12 0 L2650 S0 - 1000157855×2
- SLHYDR 2SC 10 PN12 45 PN12 0 L650,0F0 - 1000160715×2
- SLHYDR 2SC 10 PN12 0 PN12 0 L800,0F0 - 1000157864×2
- SLHYDR 1SC 13 PN15 45 PN15 0 L620,0F0 - 1000157859×1
- SLHYDR 1SC 12 PN15 0 PN15 0 L750,0F0 - 1000157865×1
- suppl. Hydraulic pedal - 1000258035×1
- Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×2
- 91000015407Not stockedhexagon nut×2
- GE12LM22X1,5OROMDA3C - 1000159921×1
- 111000015494Not stockedscrew joint×1
- 121000015493Not stockedscrew joint×2
- 131000153425Not stockedLEVER×1
- 141000069438Not stockedslide bearing×4
- 151000049219Not stockedwasher×2
- cotter pin 3,2x20 - 1000095365×2
- plate - 1000153422×2
- 181000153421Not stockedpin×2
- cotter pin - 1000151228×2
- track rod - 1000153429×1
- 211000013021Not stockedhexagon nut×1
- nut M8LHA2C - 1000128104×1
- PIVOTING BEARING - 1000142003×1
- 241000015431Not stockedwasher×2
- locking cap - 1000082961×3
- screw joint 12L 1/2" - 1000160343×2
- lock screw connection - 1000128535×1
- 281000109378Not stockedquick lock coupling×2
- Protection cap - 1000109417×2
- 301000109377Not stockedquick lock coupling×1
- Protection cap - 1000109416×1
- 321000015430Not stockedwasher×2
- 331000022386Not stockedcheese head screw×2
- PIVOTING BEARING - 1000156991×1
- plate - 1000325019×1
