WL25
WL25 front part frame Diagram
- 11000286960Not stockedfront part frame×1
- 21000492073Not stockedbracket×1
- 31000492074Not stockedbracket×1
- 41000398598Not stockedTransport securing strip×1
- Pin 1000224757×1
- Bolt 1000224743×1
- PIN - 1000241462×1
- NIPPLE-GREASE - 1000222726×1
- Bearing - 1000224830×1
- 101000015465Not stockedlock ring×2
- 111000049262Not stockedwasher×2
- fitting disc - 1000094768×1
- lock ring - 1000095360×1
- 141000085487Not stockedcheese head screw×4
- 151000049280Not stockedu-washer×8
- 161000018412Not stockedhexagon nut×4
- 171000047366Not stockedhex screw×2
- washer 10,5 A2C DIN125 - 1000015432×4
- nut M10-8 A2C-DIN985 - 1000015408×2
- 201000013008Not stockedhex screw×2
- 211000030951Not stockedspring washer×2
- Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×2
- 231000022016Not stockedspring washer×2
- Washer - 1000222577×2
- 251000015440Not stockedu-washer×2
- 261000015456Not stockedcotterpin×1
- plug - 1000082627×1
- locking chain - 1000082730×1
- key ring - 1000193637×1
- 301000020553Not stockedhex screw×1
- 311000015444Not stockedspring washer×1
- Washer - 1000222875×1
- 331000414235Not stockedfitting disc×3
- 341000414234Not stockedfitting disc×3
- 351000414221Not stockedshim×2
- 361000414230Not stockedshim×1
- 371000414225Not stockedshim×1
