WL20

WL20 loading system/armsystem Diagram

Exploded parts diagram of the loading system/armsystem of a Wacker Neuson WL20, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000394195Not stocked
    loading system/armsystem×1
  • 21000214640Price
    Lever 1000214640×1
  • 31000213997Price
    Tierod 1000213997×1
  • 41000224741Price
    Bolt - 1000224741×2
  • 51000225212Price
    PIN - 1000225212×1
  • 61000224370Price
    Pin 1000224370×1
  • 71000225246Price
    Gleitlag.b. MBZ 40x44x30mm - 1000225246×2
  • 81000222386Price
    Slide bearing MBZ 35x39x20mm - 1000222386×6
  • 91000222726Price
    NIPPLE-GREASE - 1000222726×7
  • 101000085411Price
    hex screw M10x20-8.8 A2C DIN933 - 1000085411×3
  • 111000015432Price
    washer 10,5 A2C DIN125 - 1000015432×2
  • 121000124882Price
    Body washer 10,5x30x2,5 - 1000124882×3
  • 141000082423Price
    hex screw - 1000082423×2
  • 151000048992Not stocked
    hexagon nut×2
  • 161000222577Price
    Washer - 1000222577×3
  • 171000224184Price
    Sleeve - 1000224184×2
  • 181000219820Price
    Slide bearing MBZ 40x44x30mm - 1000219820×4
  • 191000414769Price
    Drawbar - 1000414769×1
