RD25 ROLLER,DOUBLE DRUM
RD25 Crankcase cpl. Diagram
- 15000107539Not stockedCrankcase×1
- PIN-ROLL,8X8 - 5000107540×4
- PIN 5 X 24 ROLLED - 5000013592×2
- WASHER M12,LOCK - 5000107541×6
- SCREW M12X1.5-10.9,ALLEN - 5000107542×6
- 85000107543Not stockedStud×5
- PIN 5 X 24 ROLLED - 5000013592×1
- 105000107544Not stockedCylinder pin×1
- PIN-CYLINDER,10M6X14-ST 50K - 5000107545×2
- PIN-ROLL, 8X12 - 5000107546×2
- BEARING-NEEDLE - 5000107547×1
- STUD - 5000107548×1
- PLUG-SCREW AM22X1.5 - 5000094958×2
- SEAL-RING 22 X 27 - 5002004664×2
- FITTING-OIL FILTER - 5000107550×1
- SEAL-RING A10 X 13.5,COPR - 5000071121×1
- SCREW M10X1 5.8 A3C - 5000151213×1
- SCREW M8 X 20 HX.HD. - 5000012362×8
- WASHER-LOCK B8 - 5000012397×8
- SCREW-CLOSING - 5000107551×1
- WASHER A18X22-CU - 5000107552×1
- SPRING-PRESSURE - 5000107553×1
- VALVE-OIL RELEASE,PISTON - 5000107554×1
- STUD M6X16 - 5000107555×2
- 325000013552Not stockedHexagonal head cap screw×2
- WASHER A8X14-CU - 5000107556×2
- SCREW M8 X 16 HX.HD. - 5000012361×4
- COVER,38 - 5000107557×2
- COVER-OIL SUMP - 5000107558×1
- WASHER-LOCK B12 - 5000012648×4
- SCREW M12 X 20 8.8,SOC - 5000011531×4
- WASHER-LOCK B8 - 5000012397×12
- SCREW M8 X 16 HX.HD. - 5000012361×8
- BEARING-PUMP CAMSHAFT - 5000107559×1
- JET-SPRAY - 5000107560×1
- JET-SPRAY - 5000107561×1
