RD25 ROLLER,DOUBLE DRUM

RD25 Drum Scrapers Diagram

Exploded parts diagram of the Drum Scrapers of a Wacker Neuson RD25, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000113044Price
    Bracket - 5000113044×4
  • 25000112756Not stocked
    Bolt×4
  • 35000110127Price
    SCRAPER - 5000110127×2
  • 45000113054Price
    SCRAPER - 5000113054×2
  • 55000112725Price
    FITTING-GREASE - 5000112725×4
  • 65000113014Price
    Plate - 5000113014×2
  • 75000110139Not stocked
    Spring×4
  • 85000113015Price
    Plate - 5000113015×4
  • 95000112807Not stocked
    Lock nut×4
  • 105000112830Not stocked
    Washer×8
  • 115000112774Price
    BOLT - 5000112774×4
  • 125000112813Not stocked
    Lock nut×4
  • 135000112773Price
    BOLT - 5000112773×4
  • 145000112820Price
    Washer - 5000112820×4
  • 155000112835Not stocked
    Washer×4
  • 165000112774Price
    BOLT - 5000112774×4
  • 175000112813Not stocked
    Lock nut×4
  • 185000112768Price
    BOLT - 5000112768×12
  • 195000112812Price
    NUT-LOCK - 5000112812×12
  • 205000112992Price
    DRUM SCRAPER - 5000112992×2
  • 215000113055Price
    Plate - 5000113055×2
  • 225000113074Price
    PLATE-ANGLE - 5000113074×2
  • 235000112824Price
    Washer - 5000112824×16
  • 245000118733Not stocked
    Bracket×2
  • 255000118734Price
    BRACKET-SCRAPER,REAR - 5000118734×2
