EZ10e
EZ10E bucket cylinder Diagram
- 11000554581Not stockedbucket cylinder×1
- 21000068818Not stockedclamp×1
- 31000020553Not stockedhex screw×1
- 41000015430Not stockedu-washer×1
- 51000568121Not stockedpiston×1
- 61000403744Not stockedguide bushing×1
- Bushing - 1000403740×2
- 81000403747Not stockedslide bearing×1
- 91000572957Not stockedseal kit×1
- 101000572949Not stockedpiston rod×1
- 111000015384Not stockedthread pin×1
- plug M8 - 1000288011×4
- 131000068993Not stockedplug×1
- 141000555094Not stockedprotecting rail×1
- 151000460020Not stockedguide-element×1
- countersunk screw - 1000085531×4
- hex screw M10x20-8.8 A2C DIN933 - 1000085411×1
- 181000368878Not stockedlock washer×1
