ET08
ET08 TURNTABLE DRIVE UNIT INSTALLATION Diagram
- 11000279235Not stockedturn lever×1
- DIN985-M8-8-A2C - 1000015416×2
- COTTERPIN - 1000280926×2
- 41000428685Not stockedthread rod×1
- 51000013021Not stockedhexagon nut×2
- nut M8LHA2C - 1000128104×1
- ball and socket AS13 - 1000222383×2
- 7all and socket DIN71802-A13-M8L-CS-DK - 1000280212×1
- SLHYDR 2SC 8,0PN10 90 PN10 0 L500,0 0 - 1000076712×2
- plate - 1000249287×2
- slide bearing 17x19x15 - 1000151242×2
- PIN - 1000150905×2
- 131000015448Not stockedwasher×1
