DW30
DW30 Maintenance cover option Diagram
- 11000444856Not stockedMaintenance cover×1
- 21000392940Not stockedthread plate×4
- washer 10,5 A2C DIN125 - 1000015432×8
- hex screw M10x20-8.8 A2C DIN933 - 1000085411×8
- hinge - 1000444858×1
- hinge - 1000444852×1
- 71000069463Not stockedcylinder lock×2
- 81000068810Not stockedfelt glider×6
- 91000431711Not stockedside cover×1
- self-locking nuts M6-8 A2C-DIN985 - 1000085588×8
- 111000015430Not stockedu-washer×8
- hex screw - 1000085377×2
- SOLENOID - 1000409837×2
- 141000444855Not stockedMaintenance cover×1
- hinge - 1000444857×1
- hinge - 1000444853×1
- 171000431646Not stockedside cover×1
- nut M4-8 A2C-DIN985 - 1000082547×4
- screw - 1000223120×4
- washer - 1000094985×8
- washer A 6,4 St A2C DIN9021 - 1000095343×3
- 221000068813Not stockedrubber wheel×1
- 231000357533Not stockedhexagon nut×1
- hex screw - 1000085385×1
- bushing - 1000411248×4
- 261000444854Not stockedMaintenance cover×1
