WN Dumper 10001
10001 exhaust Diagram
- 11000062612Not stockedexhaust×1
- 21000015364Not stockedhex screw×3
- 31000015438Not stockedlock washer×9
- 41000015407Not stockedhexagon nut×4
- 51000110223Not stockedexhaust manifold×1
- clamp - 1000068303×2
- 71000068336Not stockedexhaust bracket×2
- 81000015427Not stockedhexagon nut×8
- 91000104123Not stockedexhaust hose×1
- 101000110225Not stockedcooler support×1
- 111000104082Not stockedexhaust gasket×2
- 121000137721Not stockedexhaust manifold×1
- Seal - 1000130758×1
- SCREW - 1000115555×8
- 151000137700Not stockedexhaust pipe×1
- Screw - 1000137695×2
- 171000137699Not stockedintermediate piece×1
- 181000137696Not stockedstud bolt×7
- Nut - 1000087142×7
- 201000137697Not stockedturbo charger×1
- SEAL - 1000137698×1
- 221000142058Not stockedpipe line×1
- Banjo bolt - 1000142059×2
- Washer - 1000142060×4
- 251000142091Not stockedleakoil line×1
- SEAL - 1000142092×1
- 271000142093Not stockedseal×1
