WL52 Wheel Loader

WL52 condenser aircondition Diagram

Exploded parts diagram of the condenser aircondition of a Wacker Neuson WL52, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000287753Not stocked
    fasten bow clip×1
  • 21000305457Price
    fastener angle - 1000305457×2
  • 31000315233Not stocked
    fastener angle×2
  • 41000311534Price
    plate - 1000311534×2
  • 51000222985Price
    Clamp - 1000222985×2
  • 61000228501Price
    rubber buffer - 1000228501×2
  • 71000228531Price
    Edge protection - 1000228531×0.15
  • 81000015376Not stocked
    cheese head screw×6
  • 91000015345Price
    Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×2
  • 101000015408Price
    nut M10-8 A2C-DIN985 - 1000015408×2
  • 111000015432Price
    washer 10,5 A2C DIN125 - 1000015432×4
  • 121000013008Not stocked
    hex screw×2
  • 131000015406Not stocked
    hexagon nut×1
  • 141000015431Not stocked
    washer×3
  • 151000015405Not stocked
    hexagon nut×2
  • 161000222604Price
    Washer M 6x20x1,25 - 1000222604×2
