WL52 Wheel Loader
WL52 suppl. Control circuit Diagram
- 11000307423Not stockedHose×1
- 21000307543Not stockedHose×2
- SLHYDR 2SC 12 PN15 0 PN15 90 L1600 - 1000144781×1
- 41000307523Not stockedHose×1
- SLHYDR 2SC 8,0PN10 90 PN10 0 L300,0 0 - 1000077134×1
- EL28LOMDA3C - 1000085110×1
- RED28/22LOMDA3C - 1000103445×1
- EW22LOMD - 1000020261×1
- Bracket - 1000332685×1
- hex screw M8x40-8.8 A2C DIN933 - 1000085392×3
- 111000015431Not stockedwasher×3
- 121000030951Not stockedspring washer×3
- Sleeve - 1000224199×3
