WL250

WL250(A02-01) socket Diagram

Exploded parts diagram of the socket of a Wacker Neuson WL250(A02-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 101000444010Not stocked
    connection cable×1
  • 111000434722Not stocked
    Socket×1
  • 121000229869Price
    PLUG SLEEVE - 1000229869×2
  • 131000270099Price
    BUSHING CONTACT - 1000270099×1
  • 141000229931Price
    CABLE LUG - 1000229931×1
  • 201000289762Price
    halfround screw - 1000289762×2
  • 401000463840Not stocked
    star handle×2
  • 501000461574Price
    Cover - 1000461574×1
  • 601000020553Not stocked
    hex screw×1
  • 701000015430Not stocked
    u-washer×1
