WL250

WL250(A02-01) rotating beacon Diagram

Exploded parts diagram of the rotating beacon of a Wacker Neuson WL250(A02-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 101000148030Price
    SOCKETS - 1000148030×1
  • 201000015432Price
    washer 10,5 A2C DIN125 - 1000015432×4
  • 301000015430Not stocked
    u-washer×2
  • 401000015408Price
    nut M10-8 A2C-DIN985 - 1000015408×2
  • 501000085588Price
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×1
  • 601000018400Not stocked
    hex screw×1
  • 701000015364Not stocked
    hex screw×1
  • 801000449869Not stocked
    bracket rotating beacon×1
  • 901000015345Price
    Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×1
  • 1001000422484Not stocked
    connection cable×1
  • 1101000426017Not stocked
    rotating beacon×1
