RD45-140 Tandem Roller

RD45-140 chip spreader Diagram

Exploded parts diagram of the chip spreader of a Wacker Neuson RD45-140, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100013095Not stocked
    Hydraulic motor×1
  • 25100013101Not stocked
    Chain wheel×1
  • 35100013103Not stocked
    Chain wheel×1
  • 45100013104Not stocked
    Tension pulley×1
  • 55100013102Not stocked
    Roller chain×1
  • 65100013461Not stocked
    Feather key×1
  • 75100013108Price
    Grid - 5100013108×1
  • 85100012723Price
    Cheese-head screw - 5100012723×6
  • 95100011546Price
    Pipe clip - 5100011546×6
  • 105100012937Price
    Washer - 5100012937×6
  • 115100012942Not stocked
    Spring ring×6
  • 125100017998Price
    hexagonal nut - 5100017998×6
  • 135100013105Not stocked
    Lever×1
  • 145100013106Not stocked
    Lever×1
  • 155100013111Not stocked
    Handle×1
  • 165100013107Not stocked
    Scale×1
  • 175100013113Not stocked
    Guard×1
  • 185100013110Not stocked
    Flanged bearing×1
  • 195100013109Not stocked
    Spreading shaft×1
  • 205100013120Not stocked
    Agitator finger×16
  • 1005100039051Not stocked
    Chip Spreader×1
