RD16-90 Vibratory Roller
RD16-90 Lubrication System Diagram
- PULLEY-DRIVE - 5000159336×1
- SEAL-LIP 32X50X6 - 5000155734×1
- WASHER-COPPER - 5000082184×1
- PLUG-OIL PUMP - 5000159450×1
- SPRING-OIL PUMP - 5000159312×1
- ROD-DRIVE - 5000159330×1
- SCREW M6 X 1 X 16 - 5000159478×3
- rotor - 5000160326×1
- O-RING - 5000159228×1
- SCREW-HEX HD CAP - 5000215479×1
- O-RING - 5000159235×1
- SCREW M8 X 20 - 5000084169×6
- PUMP-OIL ASSEMBLY - 5000155735×1
- O-ring - 5000160178×1
- 215000159566Not stockedGasket×1
- 225000063695Not stockedO-Ring×2
- BOLT M6 X 1 X 12 - 5000159253×18
- Copper Washer 18x24x1 - 5000159568×2
- PLUG M18 - 5000159452×2
- BOLT M6 X 1 X 12 - 5000159253×1
- CONNECTOR-OIL FILTER - 5000159341×1
- FILTER-OIL (ELEMENT) X-5100026398 - 5000155736×1
- KEY-SQUARE 8MM - 5000159261×1
- GASKET-OIL PAN - 5000159291×1
- HOSE-RETURN OIL - 5000155737×1
- 405000155738Not stockedOil pan×1
- Dipstick guard - 5000215533×1
- Dipstick-Oil - 5000155740×1
- SCREW-SPECIAL - 5000159484×2
- 755000063695Not stockedO-Ring×2
