MPU29A
MPU29A Shaft Cpl. Diagram
- NUT M12 8,HEX - 5000010884×4
- WASHER-LOCK A12 - 5000031565×4
- Washer - 5000105417×4
- WASHER B5.3 FLAT - 5000010625×1
- KEY-PARALLEL - 5000400318×1
- SCREW M5 X 10 SOC.HD. - 5000024617×1
- Washer Lock DIN6796,Zinc Mechanical - 5000407043×4
- 285000404370Not stockedBolt assembly×1
- GEAR - 5000047057×1
- 315000404368Not stockedShaft×1
- 325000404367Not stockedShaft×1
- 345000404481Not stockedEccentric weight×4
- 355000404371Not stockedPiston×1
- Pin - 5000400358×1
- SLEEVE - 5000048557×1
- SEAL-RING 17 X 25 X 6.5,P32 - 5000048564×1
- BEARING BALL - 16008 - 5000402189×1
- 445000073427Not stockedCylindrical roller bearing×4
- SCREW M10 X 25 HX.HD. - 5000011440×1
- SCREW M10 X 35,GR 10.9 - 5000049125×2
- RING-RETAINING,40 X 2.5 - 5000400352×1
- 485000400351Not stockedRetaining ring×1
- BEARING - 5000174823×2
- 865000406554Not stockedBaseplate×1
- 965000125157Not stockedShockmount×4
- 1125000406556Not stockedExciter housing×1
- SCREW M10 X 120 10.9 - 5000094073×6
- SCREW M10 X 30 HX.HD - 5000011439×3
- WASHER-LOCK B10 - 5000010644×8
