G 7AI
G7AI Carburetor cpl. Diagram
- SET-CARBURETOR GASKETS - 5000074767×1
- SET-FLOAT VALVE - 5000074759×1
- FLOAT COMPL. - 5000217483×1
- Set-carburetor float - 5200000429×1
- SCREW-SET - 5000089286×1
- Screw w/washer, carb. drain - 5200000430×1
- Screw w/washer, carb. bowl - 5200000431×1
- Choke Shaft Set - 5200000432×1
- Carburetor cpl. - 5200000433×1
- SCREW-THROTTLE STOP - 5000071018×1
- Jet-main - 5200000434×1
- SET-COLLAR - 5000089281×1
- GASKET-FUEL STRAINER CUP - 5000071024×1
- Insulator-carburetor mount - 5200000436×1
- SPACER-CARBURETOR MOUNT - 5000074761×1
- Gasket-carburetor mount - 5200000437×1
- Gasket-carburetor insulator - 5200000438×1
- LEVER-CHOKE CONTROL - 5000071013×1
- LEVER-FUEL VALVE - 5000150266×1
- PLATE-FUEL VALVE SETTINGS - 5000073269×1
- SPRING-FUEL LEVER - 5000073270×1
- GASKET-FUEL VALVE LEVER - 5000073272×1
- FILTER-FUEL STRAINER CUP - 5000071023×1
- 305000156674Not stockedScrew×2
- PIN 2 X 12MM,SPRING TYPE - 5000071014×1
- JET-MAIN,SIZE 90 - 5000125841×1
- JET-MAIN #92 - 5000089290×1
- JET-MAIN #95 - 5000162702×1
- SET-PILOT JET,#38 - 5000081997×1
