Excavator EZ28
EZ28 front window Diagram
- PLUG - 1000241697×1
- Glassframe 1000267622×1
- 31000015379Not stockedhexagon nut×2
- roller-PVC - 1000003350×2
- bearing pin - 1000115574×2
- plate - 1000143251×2
- DIN985-M8-8-A2C - 1000015416×2
- locking - 1000171741×1
- locking - 1000171742×1
- flat head screw - 1000048573×2
- screw - 1000176788×6
- Bracket 1000171744×1
- rubber buffer - 1000241699×2
- 141000013021Not stockedhexagon nut×4
- Washer (Polyamid) - 1000093520×4
- hex screw - 1000143258×2
- gas strut - 1000143249×1
- wiper motor - 1000241700×1
- 191000171748Not stockedwash nozzle set×1
- water hose - 1000116971×4
- 211000171750Not stockedwiper arm×1
- 221000165450Not stockedwiper blade×1
- 231000068914Not stockednon return valve×1
- 241000001353Not stockedglue kt×1
- CABLE CLIP - 1000124830×2
- 261000015448Not stockedwasher×2
- Frontwindow 1000260321×1
- Frontwindow 1000267719×1
- 291000003866Not stockedcatch-rests×1
- 301000003867Not stockedcatch-rests×1
- 311000048130Not stockedcheese head screw×2
- allen screw M5x16-8.8 A2C DIN912 - 1000085451×2
- 331000004276Not stockedcover cap×2
- bracket - 1000241711×2
- slide window seal - 1000097236×1.2
- wash tank Incl. pump - 1000110420×1
- pump washtank - 1000125144×1
- locking cap - 1000125145×1
- allen screw M6x20-8.8 A2C-DIN912 - 1000085456×2
- 401000015436Not stockedlock washer×2
- washer A 6,4 St A2C DIN9021 - 1000095343×2
- 421000001352Not stockedglue cartridge×1
- 431000238291Not stockedball plug×1
