DV60

DV60 AXLE Diagram

Exploded parts diagram of the AXLE of a Wacker Neuson DV60, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000518741Not stocked
    axle×1
  • 21000367078Not stocked
    front axle×1
  • 31000429636Not stocked
    cardan shaft×1
  • 41000275081Not stocked
    axle bracket×4
  • 51000110250Price
    HEX SCREW - 1000110250×4
  • 61000106398Price
    NORTHLOCK DISC - 1000106398×8
  • 71000085579Price
    HEXAGON NUT - 1000085579×4
  • 81000345446Not stocked
    wheel nut×32
  • 91000108438Price
    GE08LM14X1,5OROMDA3C - 1000108438×2
  • 101000083062Price
    GEO12LM14X1,5OMDA3C - 1000083062×2
  • 111000015519Price
    ET12LOMDA3C - 1000015519×1
  • 121000000542Price
    EW08LOMD - 1000000542×2
  • 131000000573Not stocked
    screw joint×1
  • 141000085502Price
    allen screw M10x30 Geomet 500A DIN912 - 1000085502×16
  • 151000357535Not stocked
    hexagon nut×16
  • 161000324786Not stocked
    axle bracket×2
  • 171000047559Not stocked
    hex screw×8
  • 181000021948Not stocked
    hexagon nut×8
  • 191000094973Price
    NORTHLOCK DISC - 1000094973×16
  • 201000321993Not stocked
    plate×4
  • 211000384224Not stocked
    mounting bracket×1
  • 221000085370Price
    hex screw - 1000085370×6
  • 231000015450Not stocked
    northlock disc×6
