DT12

DT12P control valve (Option) Diagram

Exploded parts diagram of the control valve (Option) of a Wacker Neuson DT12P, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000273154Price
    Distributorblock 1000273154×1
  • 21000270658Price
    LOCK PLUG - 1000270658×3
  • 31000273278Price
    SEAL RING - 1000273278×5
  • 41000273277Price
    WASHER - 1000273277×8
  • 51000272182Price
    seal kit control valve - 1000272182×1
  • 61000270645Price
    DOUBLE NIPPLE - 1000270645×2
  • 71000271815Price
    WASHER - 1000271815×2
  • 81000085318Price
    6-Point screw M8x60-8.8 A2C-DIN931 - 1000085318×2
  • 91000015431Not stocked
    washer×2
  • 101000269279Price
    hexagon nut - 1000269279×2
  • 111000270664Price
    screw joint - 1000270664×1
  • 121000270647Price
    MINIMESS POINT - 1000270647×1
  • 131000271298Price
    DOUBLE NIPPLE - 1000271298×4
  • 141000270693Price
    Screw Joint - 1000270693×4
  • 151000270109Price
    bellow - 1000270109×1
  • 161000282863Price
    extension - 1000282863×2
  • 171000273155Price
    lever - 1000273155×2
  • 181000273116Price
    BALL HANDLE - 1000273116×2
  • 191000516808Not stocked
    spring set×2
  • 201000484812Not stocked
    lever support×2
