DT12
DT12P PUMP UNIT Diagram
- 11000525756Not stockedHYDRAULIC PUMP×1
- lever - 1000322561×2
- 31000386563Not stockedadjust device×2
- cheese head screw - 1000085467×2
- REDUCTION - 1000273055×3
- PIPE BOW - 1000273323×1
- Adapter 3/4"BSP-1/2"BSP - 1000281845×5
- seal plate - 1000271906×9
- SCREW JOINT - 1000274274×1
- SEAL RING - 1000273278×8
- BANJO BOLT - 1000274319×2
- SCREW JOINT - 1000276567×1
- MINIMESS POINT - 1000270647×5
- 141000322536Not stockedseal kit×1
- DIN985-M8-8-A2C - 1000015416×4
- Flat Head Screw - 1000285454×4
- DOUBLE NIPPLE - 1000270645×2
- ADAPTER - 1000270695×1
- extension - 1000271799×1
- SLHYDR 1SC 10 RN3/80 RN3/80 L230,0 0 - 1000270868×1
- WASHER - 1000322441×1
- 221000018400Not stockedhex screw×4
- 231000322540Not stockedhexagon nut×4
- Joint - 1000525862×1
- gear pump - 1000272979×1
- O-RING - 1000272984×1
- ADAPTER - 1000271299×1
- 281000030951Not stockedspring washer×2
- Washer - 1000272815×2
- cheese head screw - 1000249995×2
- EXTENSION - 1000273322×1
- 321000525757Not stockedwasher×2
- banjo bolt - 1000270650×1
- 341000015431Not stockedwasher×2
- screw joint - 1000525708×2
