DPU7060Fet

DPU7060FET Muffler Diagram

Exploded parts diagram of the Muffler of a Wacker Neuson DPU7060FET, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000204500Not stocked
    Muffler×1
  • 25100006308Not stocked
    Contact safety device×1
  • 35000204758Not stocked
    Countersunk screw×8
  • 45000204690Not stocked
    Washer×12
  • 55000204501Not stocked
    Seal×2
  • 65000204624Not stocked
    Locknut×2
  • 75000204706Price
    BOLT M10X25,THREADED STUD - 5000204706×2
  • 85000204731Price
    NUT M10,HEX - 5000204731×2
