CRT48-35V
CRT48-35VEU Cylinder Head Diagram
- 55000216157Not stockedCylinder head×1
- GASKET-CYLINDER HEAD - 5000216063×1
- TUBE-BREATHER - 5000216066×1
- Screw - 5000216073×4
- CAP-OIL FILL - 5200002583×1
- VALVE-EXHAUST - 5200002586×2
- 345200002587Not stockedIntake valve×2
- SPRING-VALVE - 5000216044×2
- SPRING-VALVE - 5000216044×2
- HOLDER-ENGINE VALVE - 5000080974×2
- HOLDER-VALVE - 5200002588×4
- TAPPET-VALVE - 5000216074×4
- ROCKER ARM-ADJUSTER - 5000216015×2
- Spark plug - 5000216026×2
- O-Ring - 5000216080×1
- 6015200002622Not stockedHose clamp×1
- ELBOW-SPARK PLUG CAP - 5000081034×2
- SEAL-O RING - 5000216108×2
- Screw - 5000118471×1
- Screw - 5000216032×4
- SEAL-VALVE GUIDE - 5000080971×2
- BUSHING-GUIDE - 5000089719×4
- Screw - 5000216032×8
- GASKET-ROCKER COVER - 5000216065×4
- COVER-ROCKER - 5000216076×1
- ROD-PUSH - 5000216072×4
- Rocker Arm - 5000208235×4
- BRACKET-LIFTING - 5000216062×2
- PIVOT-ROCKER ARM - 5000118464×4
- BREATHER-REED - 5000216110×2
- 13755200002633Not stockedCover×2
- Screw - 5000216027×2
- clamp - 5000051797×1
- COVER-ROCKER - 5000216064×1
