BRS90

BRS90 Governor Diagram

Exploded parts diagram of the Governor of a Wacker Neuson BRS90, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 25100051860Not stocked
    control assy. (remote)×1
  • 35000158460Price
    LEVER-GOVERNOR - 5000158460×1
  • 45000071663Price
    ROD - 5000071663×1
  • 55000162666Price
    SPRING-GOVERNOR - 5000162666×1
  • 65000071664Price
    SPRING-THROTTLE CONTROL - 5000071664×1
  • 75100051861Not stocked
    lever,control×1
  • 85000071058Price
    WASHER-CONCAVE - 5000071058×1
  • 95000071057Price
    WASHER - 5000071057×1
  • 105000071062Price
    HOLDER-REMOTE CONTROL CABLE - 5000071062×1
  • 115000071064Price
    SPACER - 5000071064×1
  • 125000082012Price
    MOUNT-CONTROL - 5000082012×1
  • 135000054088Price
    SPRING-ADJUSTING - 5000054088×1
  • 145000071667Price
    Spring - 5000071667×1
  • 165000053990Price
    SCREW M6 X 12,HX.FLANGE HD. - 5000053990×2
  • 175000068966Price
    Screw - 5000068966×1
  • 195000072782Price
    NUT-LOCK M6,HEX. - 5000072782×1
  • 205000110112Price
    SCREW-PAN 5 X 16 - 5000110112×1
  • 215000081990Price
    SCREW M5 X 25 - 5000081990×1
  • 225000071056Price
    NUT M6,HEX,FLANGE - 5000071056×1
