PSG2 500
Despiece de Pump Components · PSG2500
- 5000175110PrecioGASKET-O RING SET - 5000175110×1
- 15000150399No la vendemosPower cable×1
- BOLT-M5 X 15 - 5000150741×2
- cover - 5000150418×1
- Bolt - 5000175113×2
- Handle - 5000175094×1
- 65000174983No la vendemosMale coupling×1
- GASKET-HOSE COUPLING - 5000175097×1
- 85000175095No la vendemosAcorn nut×2
- COVER-OUTER - 5000175092×1
- Bolt - 5000175225×3
- COVER-MOTOR HEAD - 5000157373×1
- GASKET - 5000150691×1
- Capacitor - 5000157364×1
- WIRE-GROUNDING - 5000157376×1
- SCREW-M4 X 4 - 5000150777×1
- HOUSING-COVER - 5000150551×1
- WASHER-SPRING - 5000150766×1
- BEARING-BALL - 5000150555×1
- ROTOR - 5000157367×1
- 225000157368No la vendemosBearing collar×1
- BEARING-BALL - 5000150556×1
- Stator - 5000157369×1
- HOUSING-MOTOR - 5000150633×1
- O-ring - 5000150694×1
- SEAL-MECHANICAL - 5000150505×1
- LIFTER-OIL - 5000157378×1
- CASING-OIL - 5000175122×1
- BOLT-HEX,SOCKET - 5000150732×3
- PLUG-OIL - 5000150535×1
- GASKET - 5000150676×1
- CASING-PUMP - 5000175123×1
- SEAL-DUST - 5000150708×1
- sleeve - 5000150650×1
- Impeller - 5000150484×1
- WASHER-PLAIN,M8 - 5000150759×1
- WASHER-LOCK,M8 - 5000150763×1
- NUT-ACORN - 5000150753×1
- COVER-SUCTION - 5000175125×1
- STRAINER-SUCTION - 5000175126×1
- BOLT-M6 X 15 - 5000150740×3
- BOLT-STUD,M8 X 54 - 5000150791×3
