CRT48-31V-ES RIDE-ON TROWEL
Despiece de Gearbox/Left Kit · CRT48-31V-ES
- KIT-GEARBOX ASSEMBLY,LH,CRT48 - 5000160973×1
- GEARBOX-HOUSING,MACHINED - 5000115919×1
- COVER-SEAL,MACHINED P-5000176420 - 5000115920×2
- COVER-TOP,MACHINED - 5000115572×1
- GEAR-WORM,LEFT HAND - 5000115703×1
- SHAFT-OUTPUT - 5000151704×1
- SHIM-SIDE COVER,.007 WHITE - 5000163695×1
- SHIM-SIDE COVER,.009 ,GREEN - 5000163696×1
- SHIM-SIDE COVER,.012 ,ORANGE - 5000163697×2
- SHIM-SIDE COVER,.022 ,YELLOW - 5000163698×1
- SHIM-TOP COVER .009 ,GREEN - 5000163657×1
- SHIM-TOP COVER .012 ,ORANGE - 5000163658×1
- SHIM-TOP COVER .022 ,YELLOW - 5000163659×1
- SHIM-TOP COVER .032 ,RED - 5000163660×1
- COVER-FIN,LH - 5000116678×1
- 855000117044No la vendemosRelief valve×1
- FAN-CW 3.50 X 1.50,LH - 5000115940×1
- WORM 4.250 C.D. - 5000117973×1
- STUD M4 X 20 - 5000151244×2
- SCREW M4 X 14 HEX.HD. - 5000153421×2
- STUD M4 X 25 - 5000153415×2
- SCREW M6 X 40 SOC.HD. - 5000011547×1
- SCREW M8 X 20 HX.HD. - 5000012362×8
- SCREW M12 X 35 HX.HD. - 5000011422×2
- NUT-LOCK M4 HEX. - 5000010370×4
- WASHER B5.3 FLAT - 5000010625×6
- KEY-SQ 3/8 X 1-1/2,4140,320BHN - 5000115922×1
- KEY A8X7X65,SQ.ENDS,AISI 1045 - 5000151104×1
- O-RING 2-3/8 X 3/32-70 - 5000115927×2
- O-RING 7-1/4 X 1/8-70 - 5000115928×1
- SEAL-RING 2.78 X 1.625 - 5000115826×1
- BEARING-TAPERED ROLLER,CUP - 5000115847×2
- BEARING-TAPERED ROLLER,CUP - 5000115849×2
- BEARING-TAPERED ROLLER,CONE - 5000117413×2
- BEARING-TAPERED ROLLER,CONE - 5000117414×2
- SEAL-SHAFT 1.313 X 2.066 X.313 - 5000115925×2
- SEAL-SHAFT 1.625 X 2.252 X.313 - 5000115926×2
- 6165000116134No la vendemosPlug (threaded)×3
