WL60
WL60 brake assembly Diagram
- Cylinder - 1000336966×1
- 21000326710Not stockedlock cover×1
- Brake fluid container no level sensor - 1000523617×1
- bracket fuelfilter - 1000295008×1
- SLHYDR 2SC 6,0PN8 90 PN8 0 L2700 0 - 1000076582×1
- 51000329557Not stockedHose×1
- Fuel hose 8,0x3,0mm - 1000527471×2
- 71000320842Not stockedoil distributor×1
- Bolt - 1000321007×1
- 91000028739Not stockedscrew joint×4
- Bowdencable 1000222749×1
- SLHYDR 1SN 8,0PN10 45 PN10 90 L700,0 0 - 1000221728×1
- CONNECTOR-SWIVEL HEAD - 1000222571×1
- 131000392134Not stockedclamp×2
- SLHYDR 2SN 12 PN15 0 PN15 45 L1350 S - 1000263676×1
- 151000013014Not stockedcheese head screw×2
- 161000015407Not stockedhexagon nut×1
- 171000015406Not stockedhexagon nut×2
- 181000015431Not stockedwasher×4
- 191000030951Not stockedspring washer×8
- 201000018400Not stockedhex screw×2
- self-locking nuts M6-8 A2C-DIN985 - 1000085588×4
- 221000015430Not stockedu-washer×5
- Clamp - 1000223011×1
- PLUG - 1000143655×1
- 251000015444Not stockedspring washer×1
- VERSCHR. HAUPTBREMSZYL. 22X1,5 - 1000226594×1
- seal ring - 1000224016×2
- Valve - 1000320140×1
- 291000020803Not stockedscrew joint×1
- Screw Connection M18X1,5 GRAD.EINSCHR.ST - 1000226007×1
- GE10LMEDOMDA3C - 1000085114×1
- EL10LOMD - 1000417279×1
- 331000048172Not stockedcheese head screw×2
- 341000013022Not stockedhexagon nut×2
- 351000341483Not stockedseal kit mast.brake cyl×1
- BELLOW - 1000347894×1
- Rod - 1000328548×1
