Wheel Loader
WL55/WL57 planetary housing Diagram
- Ringgear 1000265240×1
- 21000204913Not stockedgear shaft×1
- Housing 1000204750×1
- LOCK SCREW - 1000223670×1
- o-ring - 1000019051×1
- 61000048353Not stockedcheese head screw×1
- Planetaryhousing 1000204908×1
- O-Ring - 1000021329×1
- 91000021318Not stockedrotary shaft seal×2
- Roller Bearing - 1000087093×4
- Washer - 1000204911×1
- lock ring - 1000087001×1
- Wheel bolt - 1000087103×16
- 141000087113Not stockedplanet gear×6
- Roller bearing - 1000087094×6
- Angle ring - 1000087084×12
- 171000021356Not stockedlock ring×6
- Ringgear 1000265240×1
- 21000204913Not stockedgear shaft×1
- Housing 1000204750×1
- LOCK SCREW - 1000223670×1
- o-ring - 1000019051×1
- 61000048353Not stockedcheese head screw×1
- Planetaryhousing 1000204908×1
- O-Ring - 1000021329×1
- 91000021318Not stockedrotary shaft seal×2
- Roller Bearing - 1000087093×4
- Washer - 1000204911×1
- lock ring - 1000087001×1
- Wheel bolt - 1000087103×16
- 141000087113Not stockedplanet gear×6
- Roller bearing - 1000087094×6
- Angle ring - 1000087084×12
- 171000021356Not stockedlock ring×6
