WL20e

WL20E(A09-01) FRONTLIGHTS Diagram

Exploded parts diagram of the FRONTLIGHTS of a Wacker Neuson WL20E(A09-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 101000015432Price
    washer 10,5 A2C DIN125 - 1000015432×6
  • 201000450953Not stocked
    bracket headlight×1
  • 301000450952Not stocked
    bracket headlight×1
  • 501000461347Not stocked
    headlight×1
  • 601000461348Not stocked
    headlight×1
  • 701000435776Not stocked
    modul×1
  • 801000047430Not stocked
    hex screw×6
  • 901000462956Not stocked
    protection plate×1
  • 1001000462957Not stocked
    protection plate×1
  • 1101000085384Price
    6-Point screw M6x25-8.8 A2C-DIN933 - 1000085384×4
  • 1201000222875Price
    Washer - 1000222875×8
  • 1301000085588Price
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×4
  • 1401000496158Not stocked
    plate×2
