RTL EU Sunbelt
RTD-SC4 Fuel Injection System Diagram
- NUT-FLANGED - 5000063700×6
- PUMP-INJECTION - 5000160379×3
- STUD - 5200009479×6
- O-ring - 5000159233×3
- 55100042196Not stockedPlate×1
- spark arrester - 5000159318×3
- WASHER-COPPER - 5000159300×3
- ROD-PUSH - 5000159246×3
- screw - 5000159473×6
- Pipe - 5000159459×1
- O-RING - 5000159237×6
- seal - 5000160209×1
- VALVE-CHECK - 5000160391×3
- GASKET - 5000159302×3
- 155200009480Not stockedSpacer×1
- SPACER - 5000159278×3
- JET-NOZZLE - 5000155710×3
- O-RING 25 X 12 X 1.78 - 5000159238×3
- 225200009491Not stockedSpring×3
- GASKET - 5200009492×3
- RING 20 X 35 X 1.78 - 5000159236×3
- spring - 5000159317×3
- CIRCLIP - 5000159242×3
- VALVE-PRESSURE - 5200015520×3
- shim - 5000159309×3
