ML240 Light Tower
ML240 Cart cpl. Diagram
- 15000403224Not stockedCart×1
- Axle Arm-Right - 5000403186×1
- Axle Arm-Left - 5000403191×1
- 45000403202Not stockedBushing×2
- Axle-Rod - 5000403195×1
- Solid Wheel 12 - 5000406613×4
- Axle - 5000403283×2
- 95000403200Not stockedHandle×1
- 105000403204Not stockedGuide plate×1
- 115000404699Not stockedConnecting rod cpl.×1
- Bushing - 5000403350×2
- 155000406589Not stockedShaft cpl.×1
- Brake Foot Cpl. - 5000403354×2
- 175000403361Not stockedFoot plate cpl.×1
- 225000403586Not stockedHolder×1
- 235000403592Not stockedCam×1
- 245000403587Not stockedHolder×1
- 255000403593Not stockedRight cam Lock×1
- Stablizer Weldment Left - 5000406611×1
- 275000406612Not stockedLever×1
- Bolt-M16 x 90,Hex Hd. - 5000403368×2
- Stablizer Plug - 5000403842×2
- WASHER B17 FLAT - 5000010618×4
- WASHER B8.4 FLAT - 5000010374×6
- SCREW M8 X 25 HX.HD. - 5000011457×6
- WASHER 3/8 NOM,STEEL,FLAT - 5000025637×1
- SCREW M10 X 30 HX.HD - 5000011439×6
- NUT-LOCK M12X1.75 HEX - 5000010366×2
- NUT-LOCK M10 HEX. - 5000010365×5
- NUT-LOCK M16 HEX. - 5000013496×2
- WASHER-LOCK B10 - 5000010644×6
- 415000402335Not stockedHandle grip×1
- 605000403929Not stockedHex nut×2
- WASHER B21 FLAT - 5000010616×3
- Spring-Tension - 5000404308×1
- SCREW-SET M6 X 10 FL.PT - 5000072815×2
- Plain Bearing - 5000406509×2
