LTW20Z-1, LIGHT TOWER 60HZ, ISUZU TIER 4i
LTW20Z1 Brakes Hydraulic System Diagram
- AXLE-TRAILER,3500#,HYD P-5000112007 - 5000180746×1
- BRAKE LINE,STEEL,3/16 X 69 L - 5000180749×1
- 1135000180750Not stockedBrake line×2
- 1145000178016Not stockedBrake×2
- FITTING-TEE,3/16 LINE - 5000180751×1
- CLIP-BRAKE LINE BRACKET - 5000180753×2
- ACTUATOR-SURGE BRAKE,8000 LB - 5000180747×1
- HITCH-LUNETTE EYE,3 ID,ZINC - 5000165612×1
- 1745000180748Not stockedGuard×1
- 1755000077653Not stockedChain×2
- 1825000180755Not stockedGrommet×1
- WRAP-CABLE TIE 3.6X203MM,BLACK - 5000111458×1
- CABLE-TIE,#28-120-UV-50 - 5000173813×6
- SCREW M12 X 120,HX HD - 5000180754×3
- SCREW M12X35-10.9 HX SER FLG - 5000155247×2
- SCREW M16 X 120 HX.HD. - 5000173843×2
- NUT-LOCK M12X1.75 HEX - 5000010366×5
- NUT-LOCK M16 HEX. - 5000013496×2
- WASHER B13 FLAT - 5000010620×5
- WASHER B17 FLAT - 5000010618×4
- WASHER A13 FLAT - 5000010376×2
